Điều khiển sạc MPPT SCCM10-100 OutBack
Roll over image to zoom in
10A/100V Maximum Power Point Tracking (MPPT) charge controller
Ensures maximum yield from available solar energy
Integrated LED display for PV and battery status
Backed by OutBack Power’s global sales and support network
Thông số kỹ thuật
| SMARTHARVEST SCCM10-100 SPECIFICATIONS | |
|---|---|
| Maximum Output Current (I) | 10 |
| Nominal Battery Voltages | 12/24 |
| Input Panel Power (Wp) | 150/300 |
| Panel Intelligence | MPPT |
| Maximum Input Voltage (Voc) | 100 |
| Charging Regulation | Four stages: bulk, absorb, float and equalization |
| Bulk Voltage (VDC) | Flooded: 14.8/29.6 VRLA: 14.6/29.2 |
| Absorb Voltage (VDC) | Flooded: 14.8/29.6 VRLA: 14.4/28.8 |
| Absorb Time | 2 hours |
| Float Voltage (VDC) | Flooded: 13.2/26.4 VRLA: 13.5/27.0 |
| Equalization Voltage (VDC) (Flooded Batteries Only) |
Flooded: 15.5/31.0 |
| Equlaization Time | 1 hour |
| State of Charge Low Voltage Disconnect (V) |
11.4/22.8V |
| Low Battery Load Reconnect (VDC) | 12.4/28.8 |
| High Battery Load Disconnect (VDC) | 15.0/30.0 |
| Temperature Compensation | -5mV/°C |
| Battery Type Selection |
VRLA/Flooded—selectable via jumper. Factory default VRLA (jumper inserted) |
| Data Logging | Internal data logging up to one week, longer data logging available with monitoring software. |
| Self Consumption (mA) (Asleep/Awake) |
14/80 |
| Peak Efficiency | 97% |
| Display | 3 LEDs |
| IP Class | IP20 |
| Operating Temperature Range | -40° to 60° C |
| Humidity | 0-95% RH non-condensing |
| Dimensions HxWxD (in/cm) | 4.3×7.8×1.8 / 11.0×19.7×4.5 |
| Weight (lb/kg) | 1.10 / .50 |
| Certifications | CE, IEC/EN 62109-1 |
| Warranty | Standard 2 year |
