Tấm pin năng lượng mặt trời Hanwha Q Cells Q.PEAK DUO-G5

Tấm pin năng lượng mặt trời Hanwha Q Cells Q.PEAK DUO-G5

Nominal Power: 315 – 330 Wp
Efficiency: Up to 19.9 %
Weight:18.7 kg

The new Q.PEAK DUO-G5 is a monocrystalline solar module with power classes up to 330 Wp and an efficiency of 19.9 %. Q.PEAK DUO-G5 solar modules offer higher yields over smaller surface areas. This is made possible by the new generation of Q.ANTUM’s world-record-holding cell concept which has now been combined with state-of-the-art circuitry half cells and a six-busbar design. The front surface of the Q.PEAK DUO BLK-G5 is completely black and enhances the visual appearance of even the most exclusive residential system.

The Q CELLS Anti LID Technology eliminates light induced degradation (LID), which can greatly reduce system performance, almost completely. Other conventional monocrystalline solar cells will lose much of their initial performance, once exposed to sunlight. With Q.PEAK DUO-G5 this is not the case, thanks to Anti LID Technology.

Technical Data

Nominal Power 315 – 330 Wp
Efficiency Up to 19.9 %
Temperature Coefficient PMPP -0.37 %/K
Dimensions 1685 mm × 1000 mm × 32 mm
(including frame)
Weight 18.7 kg

Catalogue

DATASHEET Q.PEAK DUO-G5 315-330
